Samsung Omnia 2 step by step Disassembly

[Guest cpinilla1986]

I cant Find a tutorial on how to replace the faceplate, not the screen just the housing, do I have to go through the whole dissassembling process? thank you.

[Guest iTz Dukez xXi]

omg taking that omnia apart seems like a big hassle! but im tempted to clean out the dust on the screen which is pissing me off!!!! :P

Edited April 4, 2010 by iTz Dukez xXi

[Guest .:stn:.]

ROTFL I've posted FULL service manual here looooooooong time ago..

Dec 20 2009, 11:46

http://www.modaco.com/content/i8000-verizo...service-manual/

[Guest cpinilla1986]

i'm not sure if stn's reply was for me, but that manual doesnt say if it is possible to remove the faceplate without dissmantling the whole phone

[Guest NikAhmad]

Hi Friend, Any possibility to upgrade RAM and change cube hardware? If can then any affect to software?

[Guest KAJINOFE]

Now all we gotta do is wait for Omn1a II. 5 dolla

[Guest abuttio]

Does the i920 have the same chipset as the i8000?

[Guest Rufik]

Have you seen motherboard pictures in hi-res? Especialy this one:

http://www.modaco.com/index.php?act=attach...st&id=39821

I'm unable to identify all chips...

[Guest kawgirlval69]

Have you seen motherboard pictures in hi-res? Especialy this one:

http://www.modaco.com/index.php?act=attach...st&id=39821

I'm unable to identify all chips...

well i posted pics comparing the L and the std 8000 a few months ago and offered them to anyone that wanted to pm me with their email but had no takers .....

[Guest jammerlee711]

Okay! but are they not specific tools for the phone or could u use and screwdriver and the plastic? i really wish someone knows how to open the phone and replace the LCD. thanks!

hey guys can any 1 tell me what type of amp the i8000 is using?? is it max9877?? ;)

[Guest mecgyver]

Hi all,

Thank you very much for this usefull photo guide.

I succesfully disassembled my i8000 to replace a broken LCD and, most important, reassembled everything back!

The problem is that I now have a really poor quality of the image. colours are faded and several and an horizontal pattern light-dark makes me unhappy.

New display is original Samsung, and was produced the same day of the original one (!)

Do anyone know if there is a specific tool to fix what seems a calibration problem?

I tried lcdtest.exe found under windows but there are no option to modify settings.

Thanks in advance for any help will come!

[Guest nalpt]

i'm not sure if stn's reply was for me, but that manual doesnt say if it is possible to remove the faceplate without dissmantling the whole phone

I'd also like to know if there is an easier way to remove the faceplate / cover for dust removal. My screen is fine e I'd hate to not be able to re-assemble this puppy :D .

[Guest pitymonkey]

My I8000 has dust under the screen. Is there a better way to remove this without disassemble all the phone?

[Guest Pawel81]

No, You must disassembly the entire phone. Few minutes ago I ended cleaning screen. I put soft glue in the slit so no more dust, no more disassembling.

[Guest DunKnow]

Awwww... i happily disassembled my omnia II till the screen part..and when i take it up.... i found out my screen cracked.... i did this for all the sake of the dust...

[Guest starnumberone]

800Mhz CPU

Final working assembly

Excellent step by step manual . Cleaned the dust from behind my screen.

recommend using a small sponge ( I used one that my girl applyes a make up with )

THANKS

[Guest Thoddorkra]

Hello guys, i am new to this site, found out about it through Google when i searched for Samsung Omnia 2 disassembly. Had to register to see the images.

This post is really great, because i desperately want to disassemble mine in order to get rid of the dust under my screen. Getting quite annoying recently, since it is gathered in the bottom corners refracting the light and making the images blurry.

English subtitles would be nice indeed, but the images tell a lot already. Thanks for the post!

[Guest bmshou]

Mine doesnt have the gps antenna... (i8000L)

Maybe this is the reason for the slow gps lock...

And yours?

[Guest Waldemar Niemy]

nice

[Guest lukk555]

I've just managed to clean the dust under my display with this tutorial, thanks! It is a little bit more complicated than it looks, there is some sticky tape under the main board and it gives you an impression like it's just about to crash. Tricky part is the cleaning itself too, to remove all the dust and not to leave some small hairs or leftovers of the cloth.

Anyway, following the pictures from the first post seems to be a better idea than using "disassembly/assembly" part of service manual. I was trying to use it before but I just got stuck at some step and wasn't able to continue.
